Wall Touch Plate RGB Controller 12A 12/24V DC
- Buy 3 for Regular Price $46.90 each and save 6%
- Buy 6 for Regular Price $43.90 each and save 12%
| Zones | 1 Zone |
|---|---|
| Function | RGB |
| Input Voltage | 12-24V DC |
| Max Current | 12A max (4A per channel) |
| Modes | 20 colours, 19 modes |
| Weight | 135g |
| Controller Dimensions | H=120mm, W=73.5mm, D=42mm |
This wall plate RGB controller is designed for controlling any 12V or 24V RGB colour-changing product, such as our LED RGB strip light. It has a clean modern look with its white touch panel and is designed to be installed into a standard flush box recessed into the wall.
It emits a beep to indicate when a touch has registered - however this can be muted simply by pressing and holding the power button until it sounds (about 5 seconds). Repeat to turn back on.
Cycle between the 20 static colours using the palette button on the bottom left, or the 19 dynamic modes using the bottom right button. You can also use the colour wheel to choose any colour, and slide or tap your finger along the dimmer line to increase/decrease brightness.
The maximum output of this controller is 4A per channel (12A max total).
This controller remembers its last setting after power loss, so it will return to whatever mode it was on before loss occurred, including staying off if it was off initially.
All LEDstuff products are supplied with a warranty that the item is free from defects in materials and workmanship.
This item is covered for 24 months from the time of sale.
In the event of a warranty claim, LEDstuff reserves the right to repair or replace the product where applicable.
Faults due to misuse, alteration, normal wear, or accident are not covered under warranty.
