Wall Touch Plate Dimmer 8A 12/24V DC

In stock
Regular Price $49.90
  • Buy 3 for Regular Price $46.90 each and save 6%
  • Buy 6 for Regular Price $43.90 each and save 12%
Technical Data
Zones1 Zone
Input Voltage12-24V DC
Max Current8A max
Controller DimensionsH=120mm, W=73.5mm, D=42mm

This wall plate dimmer is designed for controlling any 12V or 24V single colour product, such as our LED strip light. It has a clean modern look with its white touch panel and is designed to be installed into a standard flush box recessed into the wall.

It emits a beep to indicate when a touch has registered - however this can be muted simply by pressing and holding the power button until it sounds (about 5 seconds). Repeat to turn back on.

Slide your finger along the dimmer line to increase/decrease brightness, or press and hold the arrows to adjust brightness.

The maximum output of this controller is 8A.

This controller remembers its last setting after power loss, so it will return to whatever mode it was on before loss occurred, including staying off if it was off initially.
