RGBW 32A Amplifier/Repeater (Only 7 remaining)

In stock
Regular Price $49.90
  • Buy 2 for Regular Price $47.90 each and save 4%
  • Buy 5 for Regular Price $45.90 each and save 8%
Technical Data
Input Voltage5-24V DC
Operating Life50,000 hours
Max Current32A (total)
Operating Temperature
DimensionsL=147mm (incl. tabs), W=74mm, H=34mm

This RGBW amplifier/repeater is required when running more RGBW product than a single RGBW controller is rated for. The excess is run through this RGBW amplifier with a separate power supply, but the signal comes from the one controller. As many of these RGBW amplifiers can be used as required.

It has 4 high-power channels capable of driving up to 8A per channel (32A total), and can be run from 5V to 24V DC.

The channels are internally bridged, so you can access the full capacity of the amplifier without adding external bridging wires.
