G24 Bulb 2-Pin 12W 180°
| Base Type | G24d |
|---|---|
| Housing Colour | White |
| Dimmable | No |
| Input Voltage | 85-265V AC |
| Power Consumption | 12W |
| Light Source | 60 x 2835 SMD LED |
| Output | 1200Lm |
| Efficiency | 100Lm /W |
| Average Lifetime | 50,000 hours |
| Beam Angle | ~180° |
| Light Colour | Warm White (3000K) |
| Working Temperature | -20 - 50°C |
| Dimensions | L=161.5mm, W=35mm, H=35mm |
| Weight | 121g |
| SDoC | Available on request |
This bulb is a direct replacement for a common CFL (Compact Fluorescent) PL lamps with the G24d-1, G24d-2, G24d-3, G24q-1, G24q-2 and G24q-3 markings.
The base has a 340° rotatable socket and swivels so the bulb can be directed at any angle to ensure maximum efficiency of light.
It is constructed with 60 2835 SMD Epistar LEDs that produce a light output of 1200 Lumens for an input power of 12W, giving it an efficiency of 100Lm/W. It is constructed with a plastic cover to diffuse the LEDs and an extruded aluminium side/back.
This lamp requires no external power supply to operate and can simply replace your existing G24 lamps giving you instant power savings. This 12W LED bulb is equivalent to a 20W fluorescent bulb.
This lamp is non-dimmable.
Note: LEDstuff G24 4-Pin LED bulbs can fit G24q-1, G24q-2 and G24q-3 2-pin holders. 4-pin G24 bulbs do not have an internal starter, so there is a starter in the fitting which must be bypassed before installing the LED bulb. Our 2-Pin bulbs are a direct swap for CFL G24 bulbs. The LED bulbs require 230V on the pins.
Supplier Declaration of Conformity (SDoC) is available on request - please contact us.
All LEDstuff products are supplied with a warranty that the item is free from defects in materials and workmanship.
This item is covered for 24 months from the time of sale.
In the event of a warranty claim, LEDstuff reserves the right to repair or replace the product where applicable.
Faults due to misuse, alteration, normal wear, or accident are not covered under warranty.
